• WEDM vise adjustable 100mm


Product Details

NAME SPECIFICATION APPLICATION MODEL NUMBER
WEDM vise adjustable 100mm stainless steel, vacuum harden treatment and deeply cold treatment to HRC50~55,precise adjustable in horizontal, parallel and X, Y , Z axis
Strong clamping force can stand high water pressure.
Parallelism Within 0.003/100mm
Squareness Within 0.005/100mm
Clamping range Max 100mm
Net weigh 5.6KG
WEDM MK3R-4210
WEDM vise adjustable 100mm

Product Number : MK3R-4210

Category : EDM machine tool

Manufacturer : Mykeenedm, lnc.
